Catalog

Click below for an exploded view of the SLX Hi-Speed®Dolly from 2006 to present showing parts and part numbers.

Click here to download! (To return to website, use browser arrows)

Below are catalog pictures of Collins SLX Hi-Speed® Dolly sets, Dolly accessories, Push Bumpers, and Fifth Wheelift Hitches, along with replacement components and corresponding item numbers.

Featured are three choices of dolly wheels. The latest is our Diamond-Cut Finish, Aluminum Mag Wheel, which joins our Standard Silver Steel Wheel, and our Premium Polished Aluminum Mag Wheel — who said you can’t reinvent the wheel? Patented in 2006, the first-ever 3.75×8 Aluminum Wheel was designed to mate with the first-ever patented Aluminum Greaseable Hub, both of which were invented by Collins.

First up is our patented, aluminum Carrier Dolly System, for both vehicles and motorcycles — two in one! No more need for a separate motorcycle dolly.

Next are the first four models of Collins SLX Hi-Speed® Dolly sets featuring our Diamond-Cut Finish Aluminum Mag Wheels. All dolly sets are offered with Aluminum Greaseable Hubs, either 4.80×8 Load Range ‘C’ or 5.70×8 Load Range ‘D’ tires, and either Aluminum or Steel Cross Rails (axles):

Below are the next four models of Collins SLX Hi-Speed® Dolly sets, with Standard Silver Steel Wheels. These are followed by a list of options available for all SLX Collins Hi-Speed® Dolly sets. Also, by overwhelming demand, please note that we are again offering the .180″-wall thickness option, as found in our original heavy-duty SL Dollies from 1986-2006:

Below are SLX Dolly Frames Complete with Aluminum Greaseable Hubs, Diamond-Cut Finish Aluminum Mag Wheels, and 4.80×8 Load Range ‘C’ or 5.70×8 Load Range ‘D’ tires. (Optional Zinc Plating Shown, Item No: DF-Z)

Below are SLX Dolly Frames Complete with Standard Silver Steel Wheels and either 4.80×8 Load Range ‘C’ or 5.70×8 Load Range ‘D’ tires. SLX Frames also come with Aluminum Greaseable Hubs or Standard Steel Hubs.

Below are additional configurations of SLX Dolly Frame replacements. The DF-SLX dolly body is designed to replace worn or damaged frames. All unworn components can then be transferred, with simple tools to the factory-new frame, in just minutes. A patented economical system that only Collins offers. Please note that our heavy-duty, .180″-wall thickness option is available on all SLX Dolly Frame configurations.

1986-2006 SL Dolly Frames are also available as replacements.
